Ratings table for the KLR product category
| Horsepower (HP) | SKU (Part Number) | Drawing | Amps | Height (in) | Width (in) | Depth (in) | Weight (lbs) | Temp Rise | Watts Loss |
|---|---|---|---|---|---|---|---|---|---|
| 800.0 | KLR950CCB | PDF DXF | 950 | 18.0 | 18.5 | 14.3 | 290.0 | 155 | 978.0 |
| 800.0 | KLR950BCB7 | PDF DXF | 950 | 36.0 | 28.5 | 30.3 | 316.0 | 155 | 479.0 |
| 800.0 | KLR950CCB7 | PDF DXF | 950 | 36.0 | 28.5 | 30.3 | 465.0 | 155 | 978.0 |
| 800.0 | KLR950ACB | PDF DXF | 950 | 18.0 | 18.5 | 14.3 | 295.0 | 155 | 686.0 |
| 800.0 | KLR950ACB7 | PDF DXF | 950 | 36.0 | 28.5 | 30.3 | 455.0 | 155 | 686.0 |
| 800.0 | KLR950BCB | PDF DXF | 950 | 11.4 | 14.8 | 13.0 | 160.0 | 155 | 479.0 |
| 5.0 | KLR8BTB1 | PDF DXF | 8 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 14.0 |
| 5.0 | KLR8BTBDR | PDF DXF | 8 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 14.0 |
| 5.0 | KLR8CTB | PDF DXF | 8 | 5.0 | 5.8 | 4.0 | 7.0 | 115 | 34.0 |
| 5.0 | KLR8CTB1 | PDF DXF | 8 | 6.5 | 8.0 | 6.0 | 10.0 | 115 | 34.0 |
| 5.0 | KLR8CTBDR | PDF DXF | 8 | 5.4 | 4.5 | 6.0 | 7.0 | 115 | 34.0 |
| 5.0 | KLR8ATB | PDF DXF | 8 | 4.0 | 4.2 | 3.6 | 5.0 | 115 | 27.0 |
| 5.0 | KLR8ATBDR | PDF DXF | 8 | 4.3 | 4.1 | 4.8 | 5.0 | 115 | 27.0 |
| 5.0 | KLR8BTB | PDF DXF | 8 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 14.0 |
| 5.0 | KLR8ATB1 | PDF DXF | 8 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 27.0 |
| 750.0 | KLR850CCB | PDF DXF | 850 | 18.0 | 18.5 | 14.3 | 280.0 | 155 | 850.0 |
| 750.0 | KLR850CCB7 | PDF DXF | 850 | 36.0 | 28.5 | 30.3 | 460.0 | 155 | 850.0 |
| 750.0 | KLR850BCB7 | PDF DXF | 850 | 36.0 | 28.5 | 30.3 | 310.0 | 155 | 389.0 |
| 750.0 | KLR850ACB | PDF DXF | 850 | 18.0 | 18.5 | 14.3 | 290.0 | 155 | 569.0 |
| 750.0 | KLR850ACB7 | PDF DXF | 850 | 36.0 | 28.5 | 30.3 | 450.0 | 155 | 569.0 |
| 750.0 | KLR850BCB | PDF DXF | 850 | 11.4 | 14.8 | 13.0 | 156.0 | 155 | 389.0 |
| 60.0 | KLR80BTB | PDF DXF | 80 | 7.0 | 9.0 | 6.0 | 22.0 | 115 | 105.0 |
| 60.0 | KLR80BTB3 | PDF DXF | 80 | 9.0 | 12.0 | 8.0 | 34.0 | 115 | 105.0 |
| 60.0 | KLR80CTB | PDF DXF | 80 | 9.0 | 11.0 | 7.0 | 49.0 | 115 | 154.0 |
| 60.0 | KLR80CTB4 | PDF DXF | 80 | 15.5 | 15.0 | 13.0 | 83.0 | 115 | 154.0 |
| 60.0 | KLR80ATB | PDF DXF | 80 | 9.0 | 11.0 | 6.0 | 31.0 | 155 | 129.0 |
| 60.0 | KLR80ATB4 | PDF DXF | 80 | 15.5 | 15.0 | 13.0 | 66.0 | 115 | 129.0 |
| 500.0 | KLR750BCB | PDF DXF | 750 | 11.4 | 14.8 | 13.0 | 147.0 | 155 | 372.0 |
| 500.0 | KLR750BCB7 | PDF DXF | 750 | 36.0 | 28.5 | 30.3 | 307.0 | 155 | 372.0 |
| 500.0 | KLR750CCB7 | PDF DXF | 750 | 36.0 | 28.5 | 30.3 | 455.0 | 155 | 732.0 |
| 500.0 | KLR750ACB7 | PDF DXF | 750 | 36.0 | 28.5 | 30.3 | 443.0 | 155 | 515.0 |
| 500.0 | KLR750CCB | PDF DXF | 750 | 18.0 | 17.3 | 11.5 | 260.0 | 155 | 732.0 |
| 500.0 | KLR750ACB | PDF DXF | 750 | 18.0 | 17.3 | 11.5 | 253.0 | 155 | 515.0 |
| 3.0 | KLR6CTB1 | PDF DXF | 6 | 6.5 | 8.0 | 6.0 | 10.0 | 115 | 22.0 |
| 3.0 | KLR6CTBDR | PDF DXF | 6 | 5.4 | 4.5 | 6.0 | 7.0 | 115 | 22.0 |
| 3.0 | KLR6BTB | PDF DXF | 6 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 9.0 |
| 3.0 | KLR6BTB1 | PDF DXF | 6 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 9.0 |
| 3.0 | KLR6CTB | PDF DXF | 6 | 5.0 | 5.8 | 4.0 | 7.0 | 115 | 22.0 |
| 3.0 | KLR6BTBDR | PDF DXF | 6 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 9.0 |
| 3.0 | KLR6ATBDR | PDF DXF | 6 | 4.3 | 4.1 | 4.8 | 5.0 | 115 | 17.0 |
| 3.0 | KLR6ATB | PDF DXF | 6 | 4.0 | 4.2 | 3.6 | 5.0 | 115 | 17.0 |
| 3.0 | KLR6ATB1 | PDF DXF | 6 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 17.0 |
| 450.0 | KLR600ACB5 | PDF DXF | 600 | 18.5 | 20.0 | 16.0 | 201.0 | 155 | 493.0 |
| 450.0 | KLR600BCB | PDF DXF | 600 | 11.4 | 14.0 | 9.3 | 96.0 | 155 | 338.0 |
| 450.0 | KLR600BCB5 | PDF DXF | 600 | 18.5 | 20.0 | 16.0 | 146.0 | 155 | 338.0 |
| 450.0 | KLR600CCB7 | PDF DXF | 600 | 36.0 | 28.5 | 30.3 | 435.0 | 155 | 650.0 |
| 450.0 | KLR600CCB | PDF DXF | 600 | 18.3 | 16.9 | 12.0 | 275.0 | 155 | 650.0 |
| 450.0 | KLR600ACB | PDF DXF | 600 | 11.4 | 14.8 | 13.0 | 150.0 | 155 | 493.0 |
| 40.0 | KLR55CTB4 | PDF DXF | 55 | 15.5 | 15.0 | 13.0 | 67.0 | 115 | 150.0 |
| 40.0 | KLR55ATB | PDF DXF | 55 | 7.0 | 9.0 | 6.0 | 22.0 | 115 | 113.0 |
| 40.0 | KLR55ATB3 | PDF DXF | 55 | 9.0 | 12.0 | 8.0 | 34.0 | 115 | 113.0 |
| 40.0 | KLR55BTB | PDF DXF | 55 | 5.8 | 7.2 | 5.0 | 11.0 | 115 | 70.0 |
| 40.0 | KLR55BTB2 | PDF DXF | 55 | 7.5 | 10.0 | 7.0 | 17.0 | 115 | 70.0 |
| 40.0 | KLR55CTB | PDF DXF | 55 | 9.0 | 11.0 | 6.0 | 32.0 | 115 | 150.0 |
| 2.0 | KLR4CTB | PDF DXF | 4 | 4.0 | 4.2 | 3.6 | 4.0 | 115 | 23.0 |
| 2.0 | KLR4CTB1 | PDF DXF | 4 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 23.0 |
| 2.0 | KLR4CTBDR | PDF DXF | 4 | 4.3 | 4.1 | 4.8 | 5.0 | 115 | 23.0 |
| 2.0 | KLR4ATB1 | PDF DXF | 4 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 15.0 |
| 2.0 | KLR4ATBDR | PDF DXF | 4 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 15.0 |
| 2.0 | KLR4BTB | PDF DXF | 4 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 9.0 |
| 2.0 | KLR4BTB1 | PDF DXF | 4 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 9.0 |
| 2.0 | KLR4BTBDR | PDF DXF | 4 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 9.0 |
| 2.0 | KLR4ATB | PDF DXF | 4 | 4.0 | 4.2 | 3.6 | 4.0 | 115 | 15.0 |
| 400.0 | KLR480CCB5 | PDF DXF | 480 | 18.5 | 20.0 | 16.0 | 225.0 | 155 | 522.0 |
| 400.0 | KLR480ACB | PDF DXF | 480 | 11.4 | 15.0 | 11.0 | 110.0 | 155 | 392.0 |
| 400.0 | KLR480ACB5 | PDF DXF | 480 | 18.5 | 20.0 | 16.0 | 165.0 | 155 | 392.0 |
| 400.0 | KLR480BCB | PDF DXF | 480 | 12.45 | 13.5 | 9.3 | 85.0 | 155 | 267.0 |
| 400.0 | KLR480BCB5 | PDF DXF | 480 | 18.5 | 20.0 | 16.0 | 140.0 | 155 | 267.0 |
| 400.0 | KLR480CCB | PDF DXF | 480 | 11.4 | 14.8 | 13.0 | 175.0 | 155 | 522.0 |
| 30.0 | KLR45CTB | PDF DXF | 45 | 7.0 | 9.0 | 6.0 | 24.0 | 115 | 118.0 |
| 30.0 | KLR45CTB3 | PDF DXF | 45 | 9.0 | 12.0 | 8.0 | 36.0 | 115 | 118.0 |
| 30.0 | KLR45ATB2 | PDF DXF | 45 | 7.5 | 10.0 | 7.0 | 20.0 | 115 | 74.0 |
| 30.0 | KLR45BTB | PDF DXF | 45 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 59.0 |
| 30.0 | KLR45BTB2 | PDF DXF | 45 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 59.0 |
| 30.0 | KLR45ATB | PDF DXF | 45 | 5.8 | 7.2 | 5.0 | 14.0 | 115 | 74.0 |
| 350.0 | KLR420BCB5 | PDF DXF | 420 | 18.5 | 20.0 | 16.0 | 135.0 | 155 | 275.0 |
| 350.0 | KLR420CCB | PDF DXF | 420 | 11.4 | 14.8 | 13.0 | 170.0 | 155 | 500.0 |
| 350.0 | KLR420CCB5 | PDF DXF | 420 | 18.5 | 20.0 | 16.0 | 210.0 | 155 | 500.0 |
| 350.0 | KLR420ACB | PDF DXF | 420 | 11.4 | 14.0 | 9.3 | 100.0 | 155 | 400.0 |
| 350.0 | KLR420ACB5 | PDF DXF | 420 | 18.5 | 20.0 | 16.0 | 150.0 | 155 | 400.0 |
| 350.0 | KLR420BCB | PDF DXF | 420 | 11.4 | 14.0 | 9.3 | 85.0 | 155 | 275.0 |
| 1.5 | KLR3BTB1 | PDF DXF | 3 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 5.0 |
| 1.5 | KLR3BTBDR | PDF DXF | 3 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 5.0 |
| 1.5 | KLR3CTB | PDF DXF | 3 | 4.0 | 4.2 | 3.6 | 4.0 | 115 | 14.0 |
| 1.5 | KLR3CTB1 | PDF DXF | 3 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 14.0 |
| 1.5 | KLR3CTBDR | PDF DXF | 3 | 4.3 | 4.1 | 4.8 | 5.0 | 115 | 14.0 |
| 1.5 | KLR3ATB | PDF DXF | 3 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 9.0 |
| 1.5 | KLR3ATB1 | PDF DXF | 3 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 9.0 |
| 1.5 | KLR3BTB | PDF DXF | 3 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 5.0 |
| 1.5 | KLR3ATBDR | PDF DXF | 3 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 9.0 |
| 300.0 | KLR360BCB5 | PDF DXF | 360 | 18.5 | 20.0 | 16.0 | 115.0 | 155 | 221.0 |
| 300.0 | KLR360CCB | PDF DXF | 360 | 12.8 | 14.8 | 11.0 | 156.0 | 155 | 406.0 |
| 300.0 | KLR360CCB5 | PDF DXF | 360 | 18.5 | 20.0 | 16.0 | 206.0 | 155 | 406.0 |
| 300.0 | KLR360ACB | PDF DXF | 360 | 11.4 | 14.0 | 9.3 | 98.0 | 155 | 380.0 |
| 300.0 | KLR360ACB5 | PDF DXF | 360 | 18.5 | 20.0 | 16.0 | 140.0 | 155 | 380.0 |
| 300.0 | KLR360BCB | PDF DXF | 360 | 9.0 | 11.0 | 9.0 | 65.0 | 155 | 221.0 |
| 25.0 | KLR35BTB | PDF DXF | 35 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 55.0 |
| 25.0 | KLR35BTB2 | PDF DXF | 35 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 55.0 |
| 25.0 | KLR35CTB | PDF DXF | 35 | 7.0 | 9.0 | 6.0 | 22.0 | 115 | 97.0 |
| 25.0 | KLR35CTB3 | PDF DXF | 35 | 9.0 | 12.0 | 8.0 | 34.0 | 115 | 97.0 |
| 25.0 | KLR35ATB | PDF DXF | 35 | 5.8 | 7.2 | 5.0 | 14.0 | 115 | 70.0 |
| 25.0 | KLR35ATB2 | PDF DXF | 35 | 7.5 | 10.0 | 7.0 | 20.0 | 115 | 70.0 |
| 250.0 | KLR300ACB5 | PDF DXF | 300 | 18.5 | 20.0 | 16.0 | 151.0 | 155 | 291.0 |
| 250.0 | KLR300BCB | PDF DXF | 300 | 9.0 | 11.0 | 9.0 | 54.0 | 155 | 216.0 |
| 250.0 | KLR300BCB5 | PDF DXF | 300 | 18.5 | 20.0 | 16.0 | 104.0 | 155 | 216.0 |
| 250.0 | KLR300CCB | PDF DXF | 300 | 11.4 | 15.0 | 11.0 | 122.0 | 155 | 443.0 |
| 250.0 | KLR300CCB5 | PDF DXF | 300 | 18.5 | 20.0 | 16.0 | 172.0 | 155 | 443.0 |
| 250.0 | KLR300ACB | PDF DXF | 300 | 11.4 | 14.0 | 9.3 | 101.0 | 155 | 291.0 |
| 1.0 | KLR2CTB1 | PDF DXF | 2 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 11.0 |
| 1.0 | KLR2CTBDR | PDF DXF | 2 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 11.0 |
| 1.0 | KLR2BTB | PDF DXF | 2 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 4.0 |
| 1.0 | KLR2BTB1 | PDF DXF | 2 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 4.0 |
| 1.0 | KLR2BTBDR | PDF DXF | 2 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 4.0 |
| 1.0 | KLR2CTB | PDF DXF | 2 | 4.0 | 4.2 | 3.6 | 4.0 | 115 | 11.0 |
| 1.0 | KLR2ATBDR | PDF DXF | 2 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 8.0 |
| 1.0 | KLR2ATB | PDF DXF | 2 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 8.0 |
| 1.0 | KLR2ATB1 | PDF DXF | 2 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 8.0 |
| 20.0 | KLR27ATB2 | PDF DXF | 27 | 7.5 | 10.0 | 7.0 | 17.0 | 115 | 58.0 |
| 20.0 | KLR27BTB | PDF DXF | 27 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 43.0 |
| 20.0 | KLR27BTB2 | PDF DXF | 27 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 43.0 |
| 20.0 | KLR27CTB | PDF DXF | 27 | 5.8 | 7.2 | 5.0 | 14.0 | 115 | 80.0 |
| 20.0 | KLR27CTB2 | PDF DXF | 27 | 7.5 | 10.0 | 7.0 | 20.0 | 115 | 80.0 |
| 20.0 | KLR27ATB | PDF DXF | 27 | 5.8 | 7.2 | 5.0 | 11.0 | 115 | 58.0 |
| 15.0 | KLR25CTB2 | PDF DXF | 25 | 7.5 | 10.0 | 7.0 | 20.0 | 115 | 67.0 |
| 15.0 | KLR25ATB2 | PDF DXF | 25 | 7.5 | 10.0 | 7.0 | 17.0 | 115 | 48.0 |
| 15.0 | KLR25BTB | PDF DXF | 25 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 36.0 |
| 15.0 | KLR25BTB2 | PDF DXF | 25 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 36.0 |
| 15.0 | KLR25ATB | PDF DXF | 25 | 5.8 | 7.2 | 5.0 | 11.0 | 115 | 48.0 |
| 15.0 | KLR25CTB | PDF DXF | 25 | 5.8 | 7.2 | 5.0 | 14.0 | 115 | 67.0 |
| 200.0 | KLR250CCB | PDF DXF | 250 | 11.4 | 14.0 | 10.0 | 115.0 | 155 | 353.0 |
| 200.0 | KLR250CCB5 | PDF DXF | 250 | 18.5 | 20.0 | 16.0 | 141.0 | 155 | 353.0 |
| 200.0 | KLR250ACB | PDF DXF | 250 | 11.4 | 14.0 | 9.3 | 91.0 | 155 | 261.0 |
| 200.0 | KLR250ACB5 | PDF DXF | 250 | 18.5 | 20.0 | 16.0 | 141.0 | 155 | 261.0 |
| 200.0 | KLR250BCB | PDF DXF | 250 | 9.0 | 11.0 | 8.0 | 48.0 | 155 | 161.0 |
| 200.0 | KLR250BCB4 | PDF DXF | 250 | 15.5 | 15.0 | 13.0 | 83.0 | 155 | 161.0 |
| 15.0 | KLR21BTB2 | PDF DXF | 21 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 30.0 |
| 15.0 | KLR21CTB | PDF DXF | 21 | 5.8 | 7.2 | 5.0 | 14.0 | 115 | 59.0 |
| 15.0 | KLR21CTB2 | PDF DXF | 21 | 7.5 | 10.0 | 7.0 | 20.0 | 115 | 59.0 |
| 15.0 | KLR21ATB | PDF DXF | 21 | 5.8 | 7.2 | 5.0 | 11.0 | 115 | 45.0 |
| 15.0 | KLR21BTB | PDF DXF | 21 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 30.0 |
| 15.0 | KLR21ATB2 | PDF DXF | 21 | 7.5 | 10.0 | 7.0 | 17.0 | 115 | 45.0 |
| 150.0 | KLR200BCB | PDF DXF | 200 | 9.0 | 11.0 | 7.0 | 42.0 | 155 | 135.0 |
| 150.0 | KLR200BCB4 | PDF DXF | 200 | 15.5 | 15.0 | 13.0 | 88.0 | 155 | 135.0 |
| 150.0 | KLR200CCB | PDF DXF | 200 | 11.4 | 14.0 | 9.3 | 110.0 | 155 | 337.0 |
| 150.0 | KLR200CCB5 | PDF DXF | 200 | 18.5 | 20.0 | 16.0 | 160.0 | 155 | 337.0 |
| 150.0 | KLR200ACB | PDF DXF | 200 | 12.5 | 13.5 | 9.3 | 81.0 | 155 | 222.0 |
| 150.0 | KLR200ACB5 | PDF DXF | 200 | 18.5 | 20.0 | 16.0 | 136.0 | 155 | 222.0 |
| 12.0 | KLR18ATB2 | PDF DXF | 18 | 7.5 | 10.0 | 7.0 | 17.0 | 115 | 40.0 |
| 12.0 | KLR18BTB | PDF DXF | 18 | 5.8 | 7.2 | 4.3 | 8.0 | 115 | 27.0 |
| 12.0 | KLR18BTB2 | PDF DXF | 18 | 7.5 | 10.0 | 7.0 | 14.0 | 115 | 27.0 |
| 12.0 | KLR18CTB | PDF DXF | 18 | 5.8 | 7.2 | 5.0 | 12.0 | 115 | 75.0 |
| 12.0 | KLR18CTB2 | PDF DXF | 18 | 7.5 | 10.0 | 7.0 | 18.0 | 115 | 75.0 |
| 12.0 | KLR18ATB | PDF DXF | 18 | 5.8 | 7.2 | 5.0 | 11.0 | 115 | 40.0 |
| 10.0 | KLR16BTB1 | PDF DXF | 6 | 6.5 | 8.0 | 6.0 | 11.0 | 115 | 20.0 |
| 10.0 | KLR16BTBDR | PDF DXF | 16 | 5.4 | 4.5 | 6.0 | 7.0 | 115 | 20.0 |
| 10.0 | KLR16CTB | PDF DXF | 16 | 5.8 | 7.2 | 5.0 | 12.0 | 115 | 58.0 |
| 10.0 | KLR16CTB2 | PDF DXF | 16 | 7.5 | 10.0 | 7.0 | 18.0 | 115 | 58.0 |
| 10.0 | KLR16ATB | PDF DXF | 16 | 5.0 | 6.0 | 4.0 | 8.0 | 115 | 38.0 |
| 10.0 | KLR16ATB1 | PDF DXF | 16 | 6.5 | 8.0 | 6.0 | 11.0 | 115 | 38.0 |
| 10.0 | KLR16ATBDR | PDF DXF | 16 | 5.4 | 4.5 | 6.0 | 8.0 | 115 | 38.0 |
| 10.0 | KLR16BTB | PDF DXF | 16 | 5.0 | 6.0 | 4.0 | 7.0 | 115 | 20.0 |
| 125.0 | KLR160BCB4 | PDF DXF | 160 | 15.5 | 15.0 | 13.0 | 82.0 | 155 | 127.0 |
| 125.0 | KLR160CCB | PDF DXF | 160 | 12.25 | 13.5 | 9.3 | 75.0 | 155 | 254.0 |
| 125.0 | KLR160CCB5 | PDF DXF | 160 | 18.5 | 20.0 | 16.0 | 134.0 | 155 | 254.0 |
| 125.0 | KLR160ACB | PDF DXF | 160 | 10.0 | 1.5 | 7.5 | 50.0 | 115 | 165.0 |
| 125.0 | KLR160ACB4 | PDF DXF | 160 | 15.5 | 15.0 | 13.0 | 85.0 | 115 | 165.0 |
| 125.0 | KLR160BCB | PDF DXF | 160 | 10.0 | 10.5 | 7.0 | 35.0 | 155 | 127.0 |
| 100.0 | KLR130BCB | PDF DXF | 130 | 9.0 | 11.0 | 7.0 | 33.0 | 155 | 117.0 |
| 100.0 | KLR130BCB4 | PDF DXF | 130 | 15.5 | 15.0 | 13.0 | 68.0 | 115 | 117.0 |
| 100.0 | KLR130CCB | PDF DXF | 130 | 12.5 | 13.0 | 9.3 | 75.0 | 155 | 239.0 |
| 100.0 | KLR130CCB5 | PDF DXF | 130 | 18.5 | 20.0 | 16.0 | 131.0 | 155 | 239.0 |
| 100.0 | KLR130ACB4 | PDF DXF | 130 | 15.5 | 15.0 | 13.0 | 83.0 | 115 | 148.0 |
| 100.0 | KLR130ACB | PDF DXF | 130 | 10.0 | 10.0 | 7.5 | 45.0 | 155 | 179.0 |
| 7.5 | KLR12CTB | PDF DXF | 12 | 5.0 | 5.8 | 4.0 | 7.0 | 115 | 54.0 |
| 7.5 | KLR12CTB1 | PDF DXF | 12 | 6.5 | 8.0 | 6.0 | 10.0 | 115 | 54.0 |
| 7.5 | KLR12CTBDR | PDF DXF | 12 | 5.4 | 4.5 | 6.0 | 8.0 | 115 | 54.0 |
| 7.5 | KLR12ATB1 | PDF DXF | 12 | 6.5 | 8.0 | 6.0 | 10.0 | 115 | 31.0 |
| 7.5 | KLR12ATBDR | PDF DXF | 12 | 5.4 | 4.5 | 6.0 | 7.0 | 115 | 31.0 |
| 7.5 | KLR12BTB | PDF DXF | 12 | 4.0 | 4.2 | 3.6 | 3.0 | 115 | 20.0 |
| 7.5 | KLR12BTB1 | PDF DXF | 12 | 6.5 | 8.0 | 6.0 | 7.0 | 115 | 20.0 |
| 7.5 | KLR12BTBDR | PDF DXF | 12 | 4.3 | 4.1 | 4.8 | 4.0 | 115 | 20.0 |
| 7.5 | KLR12ATB | PDF DXF | 12 | 5.0 | 5.8 | 4.0 | 7.0 | 115 | 31.0 |
| 75.0 | KLR110CCB4 | PDF DXF | 110 | 15.5 | 15.0 | 13.0 | 85.0 | 115 | 191.0 |
| 75.0 | KLR110ACB | PDF DXF | 110 | 10.0 | 10.0 | 7.0 | 49.0 | 155 | 166.0 |
| 75.0 | KLR110ACB4 | PDF DXF | 110 | 15.5 | 15.0 | 13.0 | 74.0 | 155 | 152.0 |
| 75.0 | KLR110BCB | PDF DXF | 110 | 7.0 | 9.0 | 7.0 | 26.0 | 115 | 95.0 |
| 75.0 | KLR110BCB4 | PDF DXF | 110 | 15.5 | 15.0 | 13.0 | 61.0 | 115 | 95.0 |
| 75.0 | KLR110CCB | PDF DXF | 110 | 10.0 | 10.5 | 8.0 | 50.0 | 155 | 191.0 |
